Key advantages:

Made of brass, clean and sanitary

Risk of ignition without oxygen

Reliable structure design allows trouble-free operation under all working conditions

Tests were carried out according to EN 10297

Gas type Oxygen, Oxidizing, N2O

O-ring material EPDM

Seat material Polyamid

Valve body material Brass

Helium leakage rate at high pressure 1 * 10-3 mbar l/sec (He)

Seat diameter is 4 mm 0.15748 Inches

The egress connects to All standards

The entry connects to All standards

Upper operating temperature 65 Celsius 149 Fahrenheit

Operating temperature limit -40 Celsius -40 Fahrenheit

Upper working pressure 200 bar 2900 PSI

Handwheel/handle material aluminum
